Name: Short Arc UV Lamp Source, UV Lamp Photochemistry Supplier
Brand: TOPTION
SKU: 21218275

Short Arc UV Lamp Source, UV Lamp Photochemistry Supplier

1.UV arc lamp light sources are the preferred artificial sources to simulate sunlight. The high color temperature(6000K) of the UV lamps is a close match to the solar temperature. This results in very similar solar spectra in the UV and VIS although the source has some Xenon emissions lines in the near IR.

2.Application for fluorescence, Luminescence and Phosphorescence, Absorbance and Reflectance, Photochemistry, Photolithography, Detection of optical Schlieren, Solar simulation.

3.A spherical reflector collects the output from the rear of the lamp and focuses it on or near the arc, for collection by the condenser.The output is increased by as much as 60 %.

4.The housing has precise external lamp adjusters.They let you place the arc where you want it. This is important for simplifying fiber and slit illumination. In many applications, this eliminates the need for adjust any optics located beam path outside the housing.

Main features of short arc UV light source:

1.Spectral range from UV to VIS(200-2500nm).

2.Optical axis height is 157-193mm.

3.Output beam diameter is 46mm.

4.Supports wide range of accessories.

5. Fan cooled housing.

Technical configurations of TOPTION short acr UV light source:

Model	Description	Details
TOP-UV75	75W UV Light Source	75W UV Light Source includes housing ,power supply and Lamp, the filter are optional, pls refer the following sheet.
TOP-UV100	100W UV Light Source	100W UV Light Source includes housing ,power supply and Lamp , the filter are optional.
TOP-UV150	150W UV Light Source	150W UV Light Source includes housing ,power supply and Lamp , the filter are optional.
TOP-UV180	180W UV Light Source	180W UV Light Source includes housing ,power supply and Lamp , the filter are optional.
TOP-UV250	250W UV Light Source	250W UV Light Source includes housing ,power supply and Lamp , the filter are optional.
TOP-UV300	300W UV Light Source	300W UV Light Source includes housing ,power supply and Lamp , the filter are optional.
TOP-UV450	450W UV Light Source	450W UV Light Source includes housing ,power supply and Lamp, the filter are optional.
TOP-UV500	500W UV Light Source	500W UV Light Source includes housing ,power supply and Lamp , the filter are optional.
TOP-UV550	550W UV Light Source	550W UV Light Source includes housing ,power supply and Lamp , the filter are optional.
TOP-UV700	700W UV Light Source	700W UV Light Source includes housing ,power supply and Lamp , the filter are optional.
TOP-UV900	900W UV Light Source	900W UV Light Source includes housing ,power supply and Lamp , the filter are optional.
TOP-UV1000	1000W UV Light Source	1000W UV Light Source includes housing ,power supply and Lamp , the filter are optional.
TOP-UV1600	1600W UV Light Source	1600W UV Light Source includes housing ,power supply and Lamp , the filter are optional.
TOP-UV2000	2000W UV Light Source	2000W UV Light Source includes housing ,power supply and Lamp , the filter are optional.

ISO CE certification.jpg

Our customer(1).jpg

2017-06-01 115736.jpg

If you are looking for chemical, biology, pharmaceutical, and food Quartz Photochemical Reactor from China manufacturers, suppliers and factory, or checking short arc uv lamp source, uv lamp photochemistry supplier customization and desing with professional supplier in China, please feel free to contact Toption Instrument.
