Xi'an TOPTION Instrument Co., Ltd. is one of the most reliable manufacturers and suppliers of Protein Lyophilizer | Lab Freeze Dryer for Bio-Activity in China. We provide high quality solutions & products for global customers who work in chemistry, biology, pharmaceutical, food, etc. If you have any enquiry about lab solution customization, please feel free to email us.
Optimizing Bio-Stability: TOPTION High-Precision Protein Lyophilizers
Preserving the fragile secondary and tertiary structures of proteins is the most critical challenge in modern biotechnology. TOPTION Protein Lyophilizers are specifically engineered to provide the stable, repeatable, and ultra-cold environment required to prevent denaturation and aggregation. Unlike basic food dryers, our systems utilize advanced silicon oil circulation to maintain shelf temperature uniformity within a strict ±1°C, ensuring that every vial in the batch experiences identical thermal kinetics.
Equipped with a world-class refrigeration unit capable of achieving a <-80°C condenser temperature, TOPTION systems provide rapid water capture to maintain vacuum integrity throughout the primary and secondary sublimation phases. Our GMP-compliant design includes high-mirror polished stainless steel chambers and optional automatic hydraulic stoppering systems, allowing for the sterile sealing of protein samples under vacuum. From enzymes and antibodies to complex vaccines, TOPTION provides the technical expertise and validation documentation (IQ/OQ/PQ) required for mission-critical pharmaceutical research.
Knowledge: Freeze Drying at Home: How Beginners Can Use a Freeze Dryer to Preserve Food
benefits
Your benefits from TOPTION ISO & CE certified in-situ vacuum freeze dryer
1.With electric heating shelf and PID control standard,with programmable function.
2.16 programs can be stored, each program can be set up 32 segments.
3.LCD display and record drying curves.
4.Stopper by hand is available, vacuum sealing for vials can be completed.
5.RS232 interface is optional, computer connected to display the freeze-drying curve.
6.Air-let-in valve with nitrogen is optional.
7.Eutecticpoint test device is optional.
8.Vacuum pump of freeze dryer is available.
Specification
| Model |
TPV-30FD |
TPV-50FD |
||
|
Freeze drying area |
0.2 ? |
0.1 ? |
0.4 ? |
0.6 ? |
|
Condenser temperature |
<-56? (no-loading),option <-80? (no-loading) |
|||
|
Vacuum degree |
= 10Pa |
|||
|
Water capture capacity |
3-5Kg/24h |
> 6Kg/24h |
> 10Kg/24h |
|
|
Partition board size |
400×270mm*2 |
400×270mm*1 |
300×340mm*4 |
300×340mm*6 |
|
Power |
2000W |
3000W |
5000W |
|
|
Weight |
260kg |
400kg |
400kg |
|
|
Dimension(mm) |
750×800×1390 |
700×850×1230 |
700×850×1400 |
|
|
Bulk capacity Thickness: 10mm |
2L |
1L |
4L |
6L |
|
Vial loading number (pcs) |
?12mm:1554 |
?12mm:777 |
?12mm:2916 |
?12mm:2916 |
|
?16mm:868 |
?16mm:434 |
?16mm:1600 |
?16mm:1600 |
|
|
?22mm:440 |
?22mm:220 |
?22mm:872 |
?22mm:872 |
|
