Engineering High-Concentration Omega-3: TOPTION Fish Oil Refinement
Achieving pharmaceutical-grade purity in fish oil requires an environment that eliminates impurities while safeguarding delicate fatty acids. TOPTION Fish Oil Molecular Distillation Systems are specifically engineered for the precise enrichment of EPA and DHA, leveraging an ultra-high vacuum of <0.001 mbar to operate at temperatures far below the oil's oxidation point. This ensures that the natural bio-activity is preserved while the fishy odor and color are significantly improved.
Our industrial-scale systems are the industry standard for removing harmful environmental pollutants such as Mercury, Lead, and PCBs. Constructed with premium SS316L stainless steel, TOPTION distillers feature a high-speed scraper rotor that minimizes the residence time to seconds, preventing any thermal stress. Whether you are producing high-potency Omega-3 supplements or medical-grade concentrates, our turnkey solutions provide the GMP-standard engineering and high-throughput reliability your production line demands.
Technical parameters of TOPTION this type molecular distillation equipment:
|
Type of molecular distillation |
MDS-30CE molecular distillation fish oil |
|
Maximum distillation temperature |
300 °C |
|
Minimal achievable operating pressure (depending on product) |
< 0.001mbar with rotary vane pump and oil diffusion vacuum pump. |
|
Throughput (depending on product) |
18 – 30 kg/h |
|
Evaporation surface |
0.3 m² |
|
Surface of internal condenser |
0.5 m² |
|
Wiped film system |
Scraper type film scraping rotor |
|
Maximum viscosity of product can be processed |
Under operating temperature: 5000 centipoise. |
Main features of this type short path molecular distillation system
1. Feed tank: 1L jacketed glass tank.
2. High precision gear pump feed (3-15L/H). Feed tank jacket design, can be heated and achieve heat preservation by circulating heat conduction oil.
3. Evaporator material (contact with products): S304 stainless steel. And evaporator surface: 0.06㎡.
4. Heavier component discharge system and lighter component discharge system both are 5L.
5. Heater & chiller are optional, and equipped with all necessary connections (the heat insulation pipe is made of stainless steel) to connect molecular distillation equipment.
6. Vacuum system
- Vacuum degree 10pa, need to equipped with TRP-36 vacuum pump: 9L/S.
- Vacuum degree 1pa, need equipped with TPR-36 vacuum pump + roots pump unit ZJP-150S.
- Vacuum degree 0.1pa, need to equipped with oil pump + oil diffusion pump unit T150.
CE certification for whole set molecular distillation equipment, include matched vacuum pump, temperature control system. Factory directly sale guarantee reliable quality & cheapest price, support professional customize. Now contact salesj@toptionlab.com for factory visit.
