Description
When handling high-boiling, thermally sensitive, or readily oxidized chemicals, traditional distillation generally fails. Excessive heat, long residence durations, and excessive energy consumption lead to product deterioration and low yield. This issue is resolved by Industrial Short Path Distillation Equipment. This method guarantees gentle separation, maximum purity, and exceptional recovery rates by combining high vacuum, incredibly small molecular transit distance, and effective heat transfer.
Imagine separating a complex mixture without destroying delicate compounds - this equipment makes it possible.
short path distillation setup
A complete short-path (molecular) distillation system includes a feed unit, evaporator, external cold trap, discharge unit, heating unit, refrigeration unit, and vacuum unit. The selection of each component must be appropriately tailored to the properties of the separation material, process requirements, and the company's available resources to ensure the entire system meets operational requirements.
Technical Specifications
| Host |
Model |
MDS-10A |
| Raw material tank | 5L jacketed stainless steel tank | |
| Feed | Differential pressure regulating valve | |
| Flow rate 3L-15L/H | ||
| 200W motor, electronic speed control | ||
| Evaporator | Evaporation area 0.1㎡ | |
| Film formation method: Scraper (roller optional) | ||
| Material: 316L | ||
| Mechanical seal (magnetic seal optional) | ||
| Film formation motor: 370W, mechanical infinitely variable speed, 200-1000 rpm | ||
| Cold trap | 1. 0.4㎡ refrigerated cold trap | |
| 2. 3L liquid nitrogen cold trap | ||
| 3. Dual-use cold trap | ||
| Choose 1 from 3 | ||
| Heavy material discharge | 29# ground-joint adapter | |
| 10L glass bottle, 1 bottle holder | ||
| 1 lifting platform | ||
| Light material discharge | 29# ground-joint adapter | |
| 10L glass bottle, 1 bottle holder | ||
| 1 lifting platform | ||
| Material piping | Interlayer insulation | |
| Bracket and assembly | 304 stainless steel pipe | |
| Accessories | Vacuum | 1. No-load less than 10 PA |
| 2. No-load less than 5 PA | ||
| 3. No-load less than 1 PA rotary vane Roots pump unit | ||
| 4. No-load less than 0.01 PA rotary vane molecular pump unit | ||
| Vacuum measurement | Resistor/thermocouple vacuum transmitter | |
| Main evaporator heating |
300℃/6KW UC5030 |
|
| Raw material section insulation |
200℃/3KW UT-3020 |
|
| Heavy material insulation |
200℃/3KW UT-3020 |
|
| Light material condensation and insulation | Internal cooling - high and low temperature machine | |
| Insulation - 200°C/3 kW UT-3020 | ||
| External cold trap cooling | 1. Liquid nitrogen | |
| 2. Refrigerator |
Advantages
1. Ease of Operation and Maintenance
The modular skid-mounted design simplifies installation. CIP cleaning, standard KF joints, and robust seals reduce downtime between production runs.
2. Magnetic seal guarantees reliable vacuum performance, eliminating material contamination.
3-1. Dual-pump system (rotary vane + diffusion) achieves ultra-high vacuum <1Pa.
3-2. The adjustable vacuum valve design allows for easy vacuum level adjustment during operation.
4. Unified control panel: vacuum gauge and scraper speed display, and operation in one place.
5. Insulation pipelines, ball valves, and feed tanks guarantee consistent, steady, and superior insulation performance.
6. The double cold trap design allows for effortless temperature control, enabling the effective capture of ultra-light components and residual solvents. Additionally, the dual sight glass design of the cold trap provides enhanced process visibility.
7. Heavy-duty bearing casters minimize vibration loads and mitigate the impact compounds generated during the movement of the distiller.
Applications
Pharmaceuticals & APIs
Separation and purification of active pharmaceutical ingredients, solvents, antibiotics, and intermediates. Ideal for thermally sensitive APIs requiring GMP-compliant processing.
Nutraceuticals & Essential Oils
High-value compounds such as omega-3 fatty acids, MCT oils, natural vitamins (A, D, E, K), terpenes, and fragrance oils are efficiently purified without altering their delicate aroma profiles.
Food Industry
Processing edible oils, flavors, colorants (e.g., capsanthin from chili pepper), and emulsifiers like mono- and diglycerides.
Fine Chemicals & Specialty Materials
Recovery of high-boiling solvents, separation of polymers, waxes, and epoxy resins. Used in refining PEGs, surfactants, and high-performance lubricants.
Petrochemicals
Recycling of used lubricating oils, wax purification, and production of needle coke precursors.
Cosmetics
Purification of lanolin derivatives, fatty acid esters, and botanical extracts used in skincare and haircare products.
Renewable Energy
Processing biodiesel and biomass-derived fuels, enhancing yield and purity through multi-stage molecular distillation.
Service and Support
Tailored Design:
Every system is customized according to feedstock characteristics and production goals.
On-Site Installation and Training:
Experienced engineers ensure seamless commissioning and operator training.
After-Sales Service:
Fast spare parts delivery and global service response within 48 hours.
Process Optimization:
Pilot testing, sample analysis, and scale-up consulting help customers reduce trial-and-error costs.
Customization Options:
Logo branding, power supply standards (EU, US, UK), and compliance documentation (CE, cGMP, ASME) are available.
Certificate
About us
FAQ
Q1: Can molecular distillation separate two compounds with very close boiling points?
A1: It is challenging, but possible. For example, to raise the ethyl palmitate: palmitic acid ratio from 9:1 to 96% purity, about 10–20% of the material must be distilled out. Customers are encouraged to send samples for feasibility testing.
Q2: What is the molecular distillation process for biodiesel?
A2:
Using two-stage molecular distillation, yields range between 85%–90%.
With four stages, yields improve to 90%–95%.
With six stages, yields can reach 93%–96%.
Q3: Can the gear pump used in molecular distillation be purchased separately?
A3: Yes, it can. Please confirm:
A photo of your current equipment
Whether it is for the feed or discharge position
Inlet and outlet port diameters
Q4: What is the maximum size available for a wiped film evaporator?
A4: The largest system we currently manufacture is a 10 m² wiped film evaporator with a capacity of 400 L.
Q5: How is MCT oil extracted from coconut oil?
A5: The common industrial method includes hydrolysis, rectification, and esterification. The esterified MCT oil is then purified through molecular distillation for high-quality results.
