Xi'an TOPTION Instrument Co., Ltd. is one of the most reliable manufacturers and suppliers of china high-quality centrifuge ethanol extraction equipment in China. We provide high quality solutions & products for global customers who work in chemistry, biology, pharmaceutical, food, etc. If you have any enquiry about lab solution customization, please feel free to email us.
Centrifuge Ethanol Extraction Equipment
UL certification, 15lbs-220lbs of biomass/batch, 98% extraction rate from biomass, 97% ethanol removal. This type of centrifuge ethanol extraction equipment has a high degree of automation, large processing capacity, convenient operation and maintenance, and can realize remote control.
The special structure of the ethanole extraction equipment allows the working temperature to be as low as -80℃, prevents the volatilization of ethanol, and improves production efficiency.
Specifications and Structure
|
Main parameters |
TOP-C50 |
TOP-C110 |
TOP-C220 |
|
Vessel diameter(inch) |
24 |
32 |
47 |
|
Vessel volume(L) |
110 |
251 |
565 |
|
Biomass/batch(lbs) |
50 |
110 |
220 |
|
Alcohol solvent (L) |
201 |
377 |
745 |
|
Standard Max speed(r/min) |
1500 |
1000 |
700 |
|
Optional 1： speed |
2000 |
1500 |
1000 |
|
Main motor power (kW) |
5.5/7.5 |
7.5/11 |
18.5/22 |
|
Vessel load-bearing (lbs) |
100 |
320 |
540 |
|
Dimension (L*W*H)mm |
1350*990*1300 |
1700*1200*1500 |
2200*1700*1500 |
|
Machine weight(kg) |
≈800 |
≈1400 |
≈2500 |
1. The cover is opened with a mechanical spring to help the operator easily open the cover.
2. Transmission part: using imported NSK brand bearings. Imported high-temperature water pressure lubricant. Waterproof mechanical seal.
3. Control part: adopt an integrated explosion-proof control cabinet, USA Honeywell brand inverter. All low-voltage electrical appliances are imported from Schneider, PLC, using Siemens. The Operation screen is also using Siemens.
4. A level gauge is installed to check whether the amount of alcohol soaking is sufficient at any time.
5. Safety protection device, details welcome contact salesj@toptionlab.com to get information now.
