Xi'an TOPTION Instrument Co., Ltd. is one of the most reliable manufacturers and suppliers of multiple effect rotary evaporator in China. We provide high quality solutions & products for global customers who work in chemistry, biology, pharmaceutical, food, etc. If you have any enquiry about lab solution customization, please feel free to email us.

Multiple effect rotary evaporator is widely used in chemical laboratories,modern organic laboratory,organic chemistry,molecular cooking for the preparation of distillates and extracts,to separate "low boiling" solvents such a n-hexane or ethyl acetate from compounds,etc.

rotary evaporator

Vacuum pump, low temperature circulating device, vacuum controller are available, to make rotary evaporator be more efficient, and finally make your research more accurate.

rotary evaporator

A:99°Automatic lifting

AD:180°Automatic lifting

AEx:99°Automatic lifting,Whole anti-explosion system

ADEx:180°Automatic lifting,Whole anti-explosion system

Relevant Model	RE-52A RE-52AD RE-52AEX RE-52ADEX	RE-52AA RE-52AAD RE-52AAEX RE-52AADEX	RE-2000A RE-2000AD RE-2000AEX RE-2000ADEX	RE-3000A RE-3000AD RE-3000AEX RE-3000ADEX	RE-5203A RE-5203AD RE-5203AEX RE-5203ADEX	RE-5203A RE-5203AD RE-5204AEX RE-5204ADEX		RE-5205A RE-5205AD RE-5205AEX RE-5205ADEX		RE-5000A RE-5000AD RE-5000AEX RE-5000ADEX
Rotating Flask(L)	0.5L	0.5L	2L + 1L	3L + 2L	3L	3L		5L		5L
Optional Rotating Flask(L)	0.1L, 0.25L, 1L or 2L	0.1L, 0.25L, 1L or 2L	0.1L, 0.25L, 0.5L	0.5L, 1L	2L, 1L	2L, 1L		3L, 2L, 1L		3L, 2L, 1L
Receiving Flask(L)	0.5L	0.5L	1L	2L , 1L	1L	1L		3L		3L
Lifting Type	Hand lifting	Automatic lifting	Automatic lifting	Automatic lifting	Hand lifting	Automatic lifting		Hand lifting		Automatic lifting
Condenser	Vertical	Vertical	Vertical	Vertical	Vertical	Vertical		Vertical		Vertical
Rotation Speed (rpm)	0-150	0-150	20-200	20-200	0-150	0-150		0-150		0-110
Evaporating Speed (H2O)	1.2L/H	1.2L/H	1.2L/H	1.5L/H	1.5L/H	1.5L/H		2L/H		2L/H
Reachable Vacuum Rate	<133Pa (1.33mbar, 1 Torr)
Bath Power (kw)	1.1KW	1.1KW	1.5KW	1.5KW	1.5KW	1.5KW	2.2KW		2.2KW
Staic Temp. Control Range & Wave (?)	RT-99±2	RT-99±2	RT-99±2	RT-99±0.2	RT-99(180)±0.2	RT-99(180)±0.2	RT-99(180)±0.2		RT-99(180)±0.2
Power	220V 50/60Hz	220V 50/60Hz	220V 50/60Hz	220V 50/60Hz	220V 50/60Hz	220V 50/60Hz	220V 50/60Hz		220V 50/60Hz
Note: Max evaporating speed is affected by operation setting and the performances and matching levels of supporting equipment. "A"-Automatic lifting, "D"-180? Oil Bath, "EX"-Explosion Protection, "AD"-Automatic Lifting 180? Oil Bath, "AEX"-Automatic Lifting Explosion Protection.
