Solar Glass Reactor, Photochemical Reactor, UV Reactor
Hg /Xenon/Metal Halide Lamp
8-12 quartz tubes meanwhile stirring type
All kinds of volume photochemical reactor
TOPT-II type intside-illuminated photochemical reactor
Description of TOPT-II intside-illuminated photochemical reactor ---- TOPTION factory have got technical supports from many professors of SJTU and NTU in developing period. TOPT series is mainly applied to research sample / liquid phases, fixed / simulated visible light, could reaction vessel load TiO2, Photochemical reaction under conditions of photocatalyst and so on. This series can provides samples of analytical reacting product and free radical, and to measure reacting kinetic constant, quantum yield; it is widely used in fields of Chemosynthesis, environment protection, and life science, etc.
The main part of the Figure, including the main box, electrical control mercury lamp, xenon lamp electrical controllers, light, light source cooling to protect the cold trap,stirrer , glass reactor 250ml , 500ml ,1000ml (of course ,can customized all kinds of volumes). With wheeled cart.
TOPT-II type intside-illuminated photochemical reactor is included as followings:
1, mercury lamp electrical controller for the control of 100W, 300W, 500W medium pressure mercury lamp working conditions;
2, xenon lamp electrical controller for the control of 100W, 300W, 500W or 1000W xenon lamp working conditions, (each TOPT-II type photochemical reaction apparatus standard controller and mercury xenon lamp Electric appliance controller choose one);
3, mercury xenon lamp Electric appliance controller and the controller includes the total power supply, lamp selection, lamp power supplies;
4, all quartz glass light protection or improvement of the cold trap;
5, stirrer that meet TOPT-II type glass reactors.
6, rely on device can be used in addition to the main box, also equipped with factory production down pitch-type reaction table.
7. glass reactor can be choosed from 250ml , 500ml ,1000ml (of course ,can customized all kinds of volumes).
8. a wheeled cart.
9. The supply temperature response to cold trap the pump can not only provide recycled water in order to conduct the heat generated by light absorption; provide TOPT-II type photochemical reactor of sample material response to external temperature test environment for data the globalization of uniform testing ,thus increasing the global comparison of data from similar studies and progress.
Every parts of the description
First, the main box
The main box is a series of photochemical reactor placed where light devices ,has the following characteristics:
Box of size 480mm × 420mm × 900mm, weighs about 29kg.
Inside the black box in order to reduce light reflection.
After the upper cabinets with cooling fan board, cabinets after the central board has "flow switch", can be realized off (cooling water) water alarm. After the bottom plate has two holes for the cooling water pipes, pipe and cable to connect the controller through.
Cabinets on the left there are three special socket for the box of the motor, lights and the "flow switch" to use the output plug.
Second, mercury and mercury electric controller
Provide light for the 100W,300W or 500W ,1000w,medium pressure mercury lamp of the normal operation of mercury lamps in ultraviolet light generated during the operation accounted for 40% total energy issue. Mercury lamp light in the opening 5 minutes until stable, turn off the lights need to wait 5 minutes after the order to restart. When you do need to bring sunglasses with UV protection of eye and skin damage.
Medium pressure mercury lamp of the optical parameters are as follows:
Mercury lamp spectral distribution and relative intensity as follows:
Table 2 Spectral distribution of medium pressure mercury lamp
Relative intensity %
Mercury lamp light-emitting part of the quartz tube, hand direct contact with pollutants,which affect the light intensity.Quartz commonly used outside a clean cotton cloth dampened with a small amount of alcohol, cleaning inside the use lotion.
Control panel with: the total power supply, lamp selection, lamp power supply, motors, light switches and the total time of launch and other settings, sub-time setting, lamp current meter, alarm instructions. Controller with fan heat.
Controller size is 245mm × 170mm × 180mm, weighs about 23kg.
Open the controller procedure is: select light lamp power → → → total power light starts, press start and then began a timing light.
Close control of procedures: the total lamp power → Electrical → → 5 minutes after power off the cooling water.
Controller on the back of a power input line and fuse holder.
Controller on the back of the main box for the cable plug with the corresponding interfaces.
In the main cable box connected with the controller error, or lower than normal water pressure for the cooling water, the alarm lamp will light and alarm sound, instruments unable to work.
Three, xenon lamp and xenon lamp electrical controller.
Provide light for the 100W 300W 500W or 1000W xenon lamp normal and stable operation.Controller size is 245mm × 170mm × 180mm, weight 34kg. Control panel with the exception "light select" button, other buttons with the same mercury lamp controller. Xenon lamp spectral distribution and relative intensity similar to daylight.
Xenon lamp optical parameters are as follows:
Table 3 Dimensions xenon lamps and optical parameters:
Operating Current (A)
Operating Voltage (V)
Effective arc length MM)
all improvement of the entire quartz glass light protection of the cold trap is not only high efficiency UV penetration, while working long hours away because the light source caused by temperature, ensuring access to light and reactive substances, only the experiment itself without outside influence .
Sixth, photochemical reactor temperature supply pump
Temperature supply pump, is to take mechanical forms of low-temperature liquid circulation cooling equipment. With high-temperature liquid, high-temperature water bath effect. Combination of TOPT-III type photochemical reactor, for multi-state chemical reactions work. It is a new experimental device may be used instead of dry ice and liquid nitrogen temperature response do could be done as a low temperature sink Viscosity. Bottom with a strong magnetic stirring, mixing and internal circulation system with 2 to tank the temperature more uniform, can be done individually temperature, constant temperature circulating pump to provide constant temperature cold source use and. Such as bio-pharmaceuticals, chemical engineering, food engineering, that require high-precision sample from field sources. Widely used in hospitals, scientific research, experiments and identification of biological and other aspects of the work.
TOPTION is specialized in manufacturing and selling photochemical glass reactor ,UV glass reactor system, xenon glass reactor, single-layer glass reactor,double-layer glass reactor, three-layer glass reactor,thermostatic equipment, ice maker, ultrasonic instrument, spray dryer, air dryer,extracting device and so on.
With 8-yaeas experience and after 8-year developing, we has gained increasing domestic and foreign market share and enjoyed good reputation in the industry, our products are applied to many university and scientific research facilities in many fields. We can also produce the kinds of equipments depending on your needs.We believe the quality will not let you down. TOPTION company can custimezed various specifications of glass reactor system, we believe "TOPTION" will be your "TOP OPTION".
Welcome To Customized Design! Pls don't hesitate to contact us, Welcome!!!
